PLC Controlled Natural Gas Cupola Rock Wool Production Line for 30-200mm Thickness Mineral Wool Boards

PLC Controlled Natural Gas Cupola Rock Wool Production Line for 30-200mm Thickness Mineral Wool Boards

الاسم التجاري:	Greens
الـ MOQ:	1
السعر:	US $2000000-4000000
شروط الدفع:	الاعتماد المستندي، تي/تي

معلومات مفصلة

وصف المنتج

معلومات مفصلة

مكان المنشأ:

الصين

اسم المنتج:

مصنع ماكينات ومعدات تكنولوجيا الصوف الصخري للغاز الطبيعي

الكلمة الرئيسية:

مصنع كامل لألواح الصوف الصخري مع التركيب

لون:

أختر

الجهد االكهربى:

380 فولت أو حسب الطلب

التحكم الكهربائي:

التحكم PLC

حالة:

جديد

عرض:

600 ملم - 2400 ملم

سماكة:

30-200mm

مادة خام:

البازلت \ المضافة الدولوميت

القدرات:

4-8 T/H المنتج النهائي

إبراز:

PLC Control Rock Wool Production Line,30-200mm Thickness Mineral Wool Board Production Line,Natural Gas Cupola Rock Wool Manufacturing Equipment

30-200mm Thickness Mineral Wool Board Production Line

Natural Gas Cupola Rock Wool Manufacturing Equipment

وصف المنتج

Natural Gas Cupola Rock Wool Technology And Equipment Machinery

Rock wool products are manufactured from high-quality basalt, dolomite, and other raw materials through an advanced production process. The materials undergo high-temperature melting and are centrifuged into fibers using a four-axis centrifuge at high speed. During this process, binders, dustproof oil, and water repellent are precisely sprayed into the fibers. After collection by a fiber collector, the materials are cured and cut using pendulum and three-dimensional fiber laying methods to create rock wool products in various specifications and applications.

As artificial inorganic fibers processed through high-temperature melting, rock wool products offer exceptional characteristics including lightweight construction, low thermal conductivity, superior heat insulation, and excellent flame retardancy. These properties make them widely applicable across multiple industries.

Main Energy Supply Systems

Raw coal energy supply system
Power energy supply system
Natural gas energy supply system

Technical Specifications

Product Name	Rock Wool Production Line
Automatic Grade	Automatic
Voltage	380V
Features	Automatic
Panel Thickness	30-200mm
Felt Size	1000mm (adjustable)
Panel Density	30-200 Kg/m³
Applicable Industries	Manufacturing Plant, Retail, Construction Works
Finished Products	Rock Wool Board
Usage	Building Material Production
